Protected 1100mAh 10A 18350 Button Top Battery - Wholesale Discount
Protected Button Top 18350 using the highest capacity 18350 cell on the market.
This 18350 is a great choice for a high capacity and high discharge rate small sized battery. It is PCB protected button/nipple top.
This cell compares to the 1200mAh cell some of our competitors are selling and is the same cell in the top grade, but 1200mAh is an exaggerated rating so we rate ours more realistically.
Please note as with all protected batteries the protection circuit adds a few millimeters of length so it is slightly longer than an unprotected 18350.
Manufactured into a protected battery by Liion Wholesale
These are manufactured in an ISO 9001 facility with a very high quality PCBA including a Japanese Ricoh protection IC with three FNK MOSFETs for 20A high current cutoff (most PCBs will not be able to handle this much current). This protection circuit protects the battery from mishandling, overcharge, or overdischarge while allowing the battery to do its job properly.
Tested to Safety Standards
These batteries have a UN38.3 / DOT test report available and are legal for shipping. Many protected batteries on the market actually do not have any test data and are likely illegal for shipping due to lack of UN38.3 test report. Many competitors don't realize that a separate test needs to be done on the battery assembly and that the cell test is not enough. All of our batteries include a UN38.3 report available upon request.
Quick Liion Wholesale 18350DPCB Specs:
- Manufacturer and part number: Liion Wholesale 18350Dpcb
- Max Continuous Discharging Current: 10A
- Typical Capacity: 1100 mAh (1000mAh minimum)
- Style: BUTTON top
- Approximate Dimensions (including button): 39.0mm length x 18.6 mm diameter
- Discharge cut-off voltage: 2.5V (approximate)
- Voltage: 3.6V
- Full Charge Voltage: 4.2V
- Protection Cutoff Current: ~20A
- Protection IC: Ricoh R5478N101CD
- MOSFETS: FNK10N25B (Quantity 3)
- Origin: Cell made in China, button top manufactured in China, Protection IC made in Japan. Assembled in China.
- Cell Certifications: UN38.3 test report, RoHS, MSDS
- Battery Assembly Certifications: UN38.3 test report, MSDS
